The ICL7660 / TL7660 is a popular CMOS charge pump voltage converter designed to invert a DC input voltage using just a few external capacitors. It can easily convert a +5V supply into a −5V output, making it ideal for circuits that require dual supply rails but only have a single positive supply available.
With high conversion efficiency (up to 99.9% typical in open-circuit conditions) and a wide operating range from 1.5V to 10V, this IC is well-suited for battery-powered and low-power applications. It is widely used in op-amp biasing, signal conditioning, data converters, and other analog/mixed-signal designs.
Available at Microspark Store – Your Trusted Electronic Component Store!
Key Features:
- IC Type: CMOS Voltage Converter / Charge Pump
- Models: ICL7660 / TL7660 (functionally compatible)
- Function: Positive-to-negative voltage conversion
- Simple conversion of +5V to ±5V supplies
- Voltage multiplication for various applications
- High conversion efficiency (up to 99.9% typical open-circuit efficiency)
- Wide supply voltage range: 1.5V to 10V
- Very low external component count (only capacitors)
- Package: DIP-8 (Dual Inline Package) or similar, depending on variant
Applications:
- Generating negative rails for operational amplifiers
- Single-supply systems needing a small negative voltage
- Signal conditioning and sensor interfaces
- A/D and D/A converter support circuits
- Portable and battery-powered electronics
Package Includes:
- 1 × ICL7660 CMOS Voltage Converter / TL7660
Available at Microspark Store – Your Trusted Electronic Component Store! At Microspark Store, we ensure every product is quality-checked and tested before shipping, so you can buy with confidence and start building without worries.
