The IC 74595 (SN74LS595N) is a highly popular 8-bit shift register designed to convert serial data input into parallel output, allowing efficient control of multiple outputs using only a few microcontroller pins.
It features an internal storage register (latch) that enables smooth and flicker-free output updates. Data is shifted in serially using a clock signal and then transferred to the output pins simultaneously using a latch signal.
The SN74LS595N supports cascading, allowing multiple ICs to be connected together to control a large number of outputs such as LEDs, displays, or relays. Built with TTL logic, it offers fast switching and reliable performance in digital circuits.
Available at Microspark Store – Your Trusted Electronic Component Store!
Key Features
- Function: 8-Bit Serial-In Parallel-Out Shift Register
- IC Part Number: SN74LS595N / 74595
- Logic Family: 74LS TTL
- Serial data input with clock control
- Parallel output with latch (storage register)
- Output enable (OE) and reset (MR) pins
- Cascadable for expanding outputs
- Operating Voltage: 4.75V – 5.25V
- Fast switching performance
- Package Type: DIP-16
Applications
- Expanding microcontroller output pins
- LED control (LED arrays, patterns)
- 7-segment display driving
- Relay and actuator control
- Digital output systems
Package Includes
- 1 × IC – 74595 8-Bit Shift Register (SN74LS595N)
