The CD4026BE is a CMOS integrated circuit that combines a 5-stage Johnson decade counter with a decoded 7-segment display driver in a single package. It counts clock pulses from 0 to 9 and directly drives a common cathode 7-segment display, eliminating the need for an external BCD-to-7-segment decoder.
The IC features clock, clock inhibit, reset, display enable, and carry-out functions, allowing it to be used in standalone counters or cascaded with additional CD4026BE ICs for multi-digit displays. Its low power consumption and high noise immunity make it suitable for battery-powered and embedded applications. The device operates over a wide supply voltage range of 3V to 18V, making it compatible with both 5V and higher-voltage digital systems.
The CD4026BE is commonly used in digital clocks, event counters, frequency counters, production counters, scoreboards, and educational digital electronics projects.
Available at Microspark Store – Your Trusted Electronic Component Store!
Key Features
- Model: CD4026BE (4026)
- Type: 5-Stage Johnson Decade Counter with 7-Segment Decoder/Driver
- CMOS technology for low power consumption
- Directly drives common cathode 7-segment displays
- Counts from 0 to 9
- Supply Voltage: 3V – 18V DC
- Integrated display enable function
- Clock inhibit input for count control
- Carry-out output for cascading multiple counters
- High noise immunity and stable operation
- Package Type: DIP-16
Applications
- Digital clocks and timers
- Event and pulse counters
- Frequency counters
- Digital display systems
- Industrial counting equipment
- Educational digital logic experiments
- DIY electronics and embedded projects
Package Includes
- 1 × CD4026BE 5-Stage Johnson Decade Counter IC
